DMTA-20006-01EN, Rev. B, February 2014
Accessories and Spare Parts 57
Figure 4-2 Content of the basic spare part kit (P/N: COBRA-SP-BASIC)
Table 8 Fittings and tubing spare parts list (P/N: COBRA-SP-IRRIGATION)
Item
Quantity or
length (ft)
Description
A 2 Barbed T-splitter for 1/16 in inside diameter (ID) tube
B 8 Tubing 1/16 in ID X 0.09 in OD
C 2 Barbed Y-splitter for 1/16 in ID tube
D 2 Barbed reducer for 1/16 in to 3/32 in ID tube
E 8 Blue 4 mm OD flexible tube
F1Valve QH-QS-4
G 1 QS-8-4 push-in reducer
H Supplied with
pump
Blue 8 mm OD flexible tube
I Supplied with
pump
Valve 8 mm HE-2-QS-8
A B C D E F G H I
From
pump
Supplied with the COBRA scanner
Supplied with pump
To probes
