DMTA-20006-01EN, Rev. B, February 2014
Specifications
61
5. Specifications
This chapter contains the specifications for the COBRA scanner.
5.1 General and Operating Environment Specifications
Table 10 General specifications
Parameter Va lu e
Diameter range 21.3 mm to 114.3 mm (0.84 in. to 4.50 in.)
Half scanner width
a
a. Not including probe cables and couplant tubes
59 mm (2.32 in.)
Encoder resolution 32.08 pulses/mm (815 pulses/in.)
Voltage 5V
Current 100 mA maximum
Frequency 0–3.5 kHz (maximum displacement velocity of 100 mm/s [4 in./s]
