Olympus E-1 User Manual

169
Miscellaneous
12
Maintenance
 Cleaning the camera
Turn off the camera and remove the battery before cleaning the camera.
Exterior:
T Wipe gently with a soft cloth. If the camera is very dirty, soak the cloth in mild soapy
water and wring well. Wipe the camera with the damp cloth and then dry it with a dry
cloth. If you have used the camera at the beach, use a cloth soaked in clean water and
well wrung.
Monitor and viewfinder:
T Wipe gently with a soft cloth.
Lens, mirror and focusing screen:
T Blow dust off the lens, mirror and focusing screen with a commercially available blower.
For the lens, wipe gently with a lens cleaning paper. Do not use a high-pressure bottled
blower. If high-pressure gas is sprayed onto the lens, mirror, or focusing screen by non-
authorized service persons, the camera will be damaged.
 Camera maintenance
If you have not used the camera for a long time, remove the battery and store it in a
well-ventilated, cool and dry place.
Note
● Do not use strong solvents such as benzene or alcohol, or chemically treated cloth.
● Avoid storing the camera in places where chemicals are treated, in order to protect the
camera from corrosion.
● Mold may form on the lens surface if the lens is left dirty.
● Check each part of the camera before use if it has not been used for a long time. Before
taking important pictures, be sure to take a test shot and check that the camera works
properly.
Cleaning and Checking the CCD
This camera incorporates a dust reduction function to keep dust from getting on the CCD and to
remove any dust or dirt from the CCD surface with ultrasonic vibrations. Dust reduction works
when the power switch is set to ON. This function also operates whenever PIXEL MAPPING is
activated.
Since dust reduction is activated every time the camera's power is turned on, the camera should
be held upright for the dust reduction function to be effective.

Olympus E-1 Specifications

General

Max Resolution	2560 x 1920
Image Ratio w:h	4:3
Sensor Type	CCD
Lens Mount	Four Thirds
Focal Length Multiplier	2x
White Balance Presets	6
Digital Zoom	No
Image Stabilization	No
RAW Format	Yes
Shutter Priority	Yes
Aperture Priority	Yes
Manual Exposure Mode	Yes
Built-in Flash	No
Flash X Sync Speed	1/180 sec
Viewfinder Type	Optical (pentaprism)
LCD Screen Size	1.8"
Screen Dots	134, 000
Shutter Speed	60 - 1/4000 sec
Continuous Shooting	3 fps
Storage Type	CompactFlash (Type I or II), Microdrive
USB	USB 1.1
Dimensions	141 x 104 x 81 mm (5.55 x 4.09 x 3.19 in)
Camera Type	SLR
Effective Pixels	5.0 MP
Sensor Size	17.3 x 13.0 mm
Metering Modes	Center-weighted, Spot
Exposure Compensation	±3 EV (1/3 EV steps)
External Flash	Yes
Drive Mode	Single, Continuous, Self-timer
Self-timer	Yes (12 sec, 2 sec)
Battery	Lithium-Ion
Weight	660 g (1.46 lb)
ISO Range	100-800 (expandable to 1600, 3200)
