Olympus E-1 User Manual

55
Focus mode
Focus
4
Rotational direction of the focus ring
You can select the rotational direction of the focus ring to suit your preference for how the lens
adjusts to the focusing point. ~ “FOCUS RING” (P. 127)
Focus aid
When you focus the lens on a subject manually (by turning the focus ring), the AF confirmation
mark lights.
When 3 AF frames are selected, the camera performs focusing in the center AF frame.
AF ILLUMINATOR
When AF ILLUMINATOR is set to ON, the AF illuminator provides light automatically if
a subject is in a dark environment.
1
In the menu, select T
AF ILLUMINATOR T ON or OFF.
~ “How to use the menus” (P. 38)
AF illuminator

Olympus E-1 Specifications

General

Max Resolution	2560 x 1920
Image Ratio w:h	4:3
Sensor Type	CCD
Lens Mount	Four Thirds
Focal Length Multiplier	2x
White Balance Presets	6
Digital Zoom	No
Image Stabilization	No
RAW Format	Yes
Shutter Priority	Yes
Aperture Priority	Yes
Manual Exposure Mode	Yes
Built-in Flash	No
Flash X Sync Speed	1/180 sec
Viewfinder Type	Optical (pentaprism)
LCD Screen Size	1.8"
Screen Dots	134, 000
Shutter Speed	60 - 1/4000 sec
Continuous Shooting	3 fps
Storage Type	CompactFlash (Type I or II), Microdrive
USB	USB 1.1
Dimensions	141 x 104 x 81 mm (5.55 x 4.09 x 3.19 in)
Camera Type	SLR
Effective Pixels	5.0 MP
Sensor Size	17.3 x 13.0 mm
Metering Modes	Center-weighted, Spot
Exposure Compensation	±3 EV (1/3 EV steps)
External Flash	Yes
Drive Mode	Single, Continuous, Self-timer
Self-timer	Yes (12 sec, 2 sec)
Battery	Lithium-Ion
Weight	660 g (1.46 lb)
ISO Range	100-800 (expandable to 1600, 3200)
