Olympus E-1 User Manual

16
Getting started
1
Attaching the strap
1 Getting started
1
Thread one end of the strap through the
strap eyelet on the camera.
2
Thread the end of the strap through the
ring, then thread it through the stopper
as indicated by the arrows.
3
Thread the strap back through the other
hole of the stopper.
4
Pull the other side of the strap tight,
making sure that it is fastened securely.
5
Repeat steps 1 - 4 to attach the other
end of the strap to the other eyelet.
Note
● Be careful with the strap when you carry the camera, since it can easily catch on stray
objects, causing injury or damage.
● Attach the strap correctly as shown above so that the camera does not fall off. If the strap is
attached incorrectly and the camera falls off, Olympus is not responsible for any damage.
Ring
Strap eyelet
Stopper

Olympus E-1 Specifications

General

Max Resolution	2560 x 1920
Image Ratio w:h	4:3
Sensor Type	CCD
Lens Mount	Four Thirds
Focal Length Multiplier	2x
White Balance Presets	6
Digital Zoom	No
Image Stabilization	No
RAW Format	Yes
Shutter Priority	Yes
Aperture Priority	Yes
Manual Exposure Mode	Yes
Built-in Flash	No
Flash X Sync Speed	1/180 sec
Viewfinder Type	Optical (pentaprism)
LCD Screen Size	1.8"
Screen Dots	134, 000
Shutter Speed	60 - 1/4000 sec
Continuous Shooting	3 fps
Storage Type	CompactFlash (Type I or II), Microdrive
USB	USB 1.1
Dimensions	141 x 104 x 81 mm (5.55 x 4.09 x 3.19 in)
Camera Type	SLR
Effective Pixels	5.0 MP
Sensor Size	17.3 x 13.0 mm
Metering Modes	Center-weighted, Spot
Exposure Compensation	±3 EV (1/3 EV steps)
External Flash	Yes
Drive Mode	Single, Continuous, Self-timer
Self-timer	Yes (12 sec, 2 sec)
Battery	Lithium-Ion
Weight	660 g (1.46 lb)
ISO Range	100-800 (expandable to 1600, 3200)
