Olympus OER-Elite - 2.5 Side panel

2.5 Side panel
27
OER-Elite OPERATION MANUAL
Ch.2
2.5 Side panel
No. Nomenclature Description
1 Bar code reader attaching
holes
Used to attach the optional bar code reader (MAJ-2130).
2 Printer set attaching holes Used to attach the optional printer set (MAJ-2144). The connector hanger cannot
be attached if the printer set is already attached.
3 Stylus pen holder attaching
holes
Used to attach the provided stylus pen holder.
4 Connector hanger
attaching holes
Used to attach the optional connector hanger (MAJ-865). The printer set cannot
be attached if the connector hanger is already attached.
5 Grommet attaching holes
(×4)
Used to attach the grommets.
1
Left Right
2
3
4
5
