16
Outline of Functions
OER-Elite OPERATION MANUAL
Following functions are available in this reprocessor.
Reprocessing
A series of operations that enable the reprocessor to perform ultrasonic cleaning, detergent
cleaning, disinfection, rinse, air purge, and alcohol flush. A series of operations for ultrasonic
cleaning, detergent cleaning, disinfection, rinse, air purge, and alcohol flush of the outer surface
and channels of endoscopes in a specified sequence and for a specified time. Reprocessing
programs [1] to [4] can be selected by the user. Programs [1] to [4] have a fixed cleaning
process time and disinfection process time. They also have different patterns of auto leak test
and channel monitoring respectively. For details, refer to Chapter 6, “Reprocessing Operations”.
Heat LCG
A process for heating disinfectant solution until it reaches the specified temperature (22q, 72qF).
This process is performed automatically during the reprocessing program. It can also be
performed as an independent operation. For details, refer to Section 7.2, “Heat LCG”.
Heat LCG Timer
The function for heating the disinfectant solution until the specified temperature (22q, 72qF) by
the specified time. For details, refer to Section 7.3, “Heat LCG Timer”.
Drain LCG
This function drains the disinfectant solution from the disinfectant tank. For details, refer to
Section 8.2, “Replacing the disinfectant solution”.
Load LCG
This function loads the disinfectant solution after inserting a new disinfectant bottle. For details,
refer to Section 8.2, “Replacing the disinfectant solution”.
Mix LCG
This function mixs the disinfectant solution to the appropriate concentration and enables
accurate concentration check.
Outline of Functions
