Olympus OER-Elite - Entering by the software keyboard

48
3.6 Entering ID
OER-Elite OPERATION MANUAL
Ch.3

Entering by the software keyboard
An ID can be entered by the software keyboard (on-screen) on the touch screen as described below.
1 If it is during the reprocessing process, press or button on the Reprocessing
Standby screen. If it is during the leaking scope decontamination, press button on
the ID input screen.
Figure 3.16
2 Then, the ID select screen is displayed.
No. Button Note
1 “Edit” button of
scope ID
Opens the scope ID list.
2 “Edit” button of
patient ID
Opens the patient ID list.
3 “Edit” button of
physician ID
Opens the physician ID list.
4 “Edit” button of
user ID (load)
Opens the user ID (load) list.
5 “Edit” button of
procedure ID
Opens the procedure ID list.
Reprocessing Leaking scope decontamination
1
2
3
4
5
