CS/CJ/NSJ Series Instructions Reference Manual (W474)
Display Instructions
3
MSG
Display Instructions
MSG
Applicable Program Areas
Operands
N: Message number
The message number must be 0000 to 0007 hexadecimal (or 0 to 7 decimal).
M: First message word
When displaying a message, M specifies the address of the first of the words containing the ASCII
message. When clearing a message, M can be any hexadecimal constant (0000 through FFFF).
z Operand Specifications
Flags
Instruction Mnemonic Variations
Function
code
Function
Display Instructions MSG @MSG 046
Reads the specified sixteen words of extended
ASCII and displays the message on a Peripheral
Device such as a Programming Console.
Symbol
MSG
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or transition
programs
Usage OK OK OK OK OK OK
Operand Description Data type Size
N Message number UINT 1
M First message word UINT Variable
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
N
OK OK OK OK OK OK OK OK OK OK OK
OK
--- OK --- --- --- ---
M ---
Name Label Operation
Error Flag ER • ON if the content of S is not 0000 to 0007 hexadecimal.
• OFF in all other cases.
N: Message number
M: First message word
MSG(046)
N
M
