3. Instructions
304
CS/CJ/NSJ Series Instructions Reference Manual (W474)
MOVR/MOVRW
Applicable Program Areas
z MOVR
z MOVRW
Operands
z Operand Specifications
Flags
Note In CS1D CPU Units for Duplex Systems, CS1 CPU Units, and CJ1 CPU Units, these are turned OFF.
Instruction Mnemonic Variations
Function
code
Function
MOVE TO REGISTER MOVR @MOVR 560
Sets the PLC memory address of the specified
word, bit, or timer/counter Completion Flag in the
specified Index Register.
MOVE TIMER/COUNTER PV
TO REGISTER
MOVRW @MOVRW 561
Sets the PLC memory address of the specified
timer or counter's PV in the specified Index Regis-
ter.
Symbol
MOVR MOVRW
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or
transition programs
Usage OK OK OK OK OK OK
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or
transition programs
Usage Not allowed OK OK OK OK Not allowed
Operand Description
Data type
Size
MOVR MOVRW
S
MOVR: Source (desired word or bit)
MOVRW: Source (desired TC number)
BOOL UINT 1
D Destination WORD WORD 2
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
MOVR
SOKOKOKOKOKOKOKOK
--- --- --- ---
---
---
OK
--- --- ---
D --- --- --- --- --- --- --- --- OK ---
MOVRW
S
--- --- --- ---
OK OK
--- --- --- --- --- ---
---
--- --- --- --- ---
D------ OK
Name Label Operation
Error Flag ER Unchanged (See note.)
Equals Flag = Unchanged (See note.)
Negative Flag N Unchanged (See note.)
MOVR(560)
S
D
S: Source
(desired word or bit)
D: Destination
(Index Register)
MOVRW(561)
S
D
S: Source
(desired TC number)
D: Destination
(Index Register)
