3. Instructions
672
CS/CJ/NSJ Series Instructions Reference Manual (W474)
SCL
Applicable Program Areas
Operands
P1: First Parameter Word
z Operand Specifications
Instruction Mnemonic Variations
Function
code
Function
SCALING SCL @SCL 194
Converts unsigned binary data into unsigned BCD
data according to the specified linear function.
Symbol
SCL
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or
transition programs
Usage OK OK OK OK OK OK
Operand Description Data type Size
S Source word UINT 1
P1 First parameter word LWORD 4
R Result word WORD 1
Note P1 to P1+3 must be in the same area.
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
S
OK OK OK OK OK OK OK OK OK OK ---
OK
--- OK --- --- --- ---P1 ---
R OK
S: Source word
P1: First parameter word
R: Result word
SCL(194)
S
P1
R
P1
P1+1
P1+2
P1+3
15 0
15 0
15 0
15 0
Scaled value for point A (Ar)
0000 to 9999 (4-digit BCD)
Unscaled value for point A (As)
0000 to FFFF (binary)
Scaled value for point B (Br)
0000 to 9999 (4-digit BCD)
Unscaled value for point B (Bs)
0000 to FFFF (binary)
