Appendix A List of Instructions by Function Code
App
Appendix A
List of Instructions by Function Code
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
--- LOAD LD @LD %LD !LD 140
--- LOAD NOT LD NOT --- --- !LD NOT 140
--- AND AND @AND %AND !AND 142
--- AND NOT AND NOT --- --- !AND NOT 142
--- OR OR @OR %OR !OR 144
--- OR NOT OR NOT --- --- !OR NOT 144
--- AND LOAD AND LD --- --- --- 146
--- OR LOAD OR LD --- --- --- 146
--- OUTPUT OUT --- --- !OUT 158
--- OUTPUT NOT OUT NOT --- --- !OUT NOT 158
--- SET SET @SET %SET !SET 170
--- RESET RSET @RSET %RSET !RSET 170
--- HUNDRED-MS TIMER TIM --- --- --- 217
--- COUNTER CNT --- --- --- 244
000 NO OPERATION NOP --- --- --- 182
001 END END --- --- --- 181
002 INTERLOCK IL --- --- --- 183
003 INTERLOCK CLEAR ILC --- --- --- 183
004 JUMP JMP --- --- --- 196
005 JUMP END JME --- --- --- 196
006 FAILURE ALARM FAL @FAL --- --- 1018
007 SEVERE FAILURE
ALARM
FALS --- --- --- 1025
008 STEP DEFINE STEP --- --- --- 784
009 STEP START SNXT --- --- --- 784
010 SHIFT REGISTER SFT --- --- --- 307
011 KEEP KEEP --- --- !KEEP 162
012 REVERSIBLE
COUNTER
CNTR --- --- --- 247
013 DIFFERENTIATE UP DIFU --- --- !DIFU 166
014 DIFFERENTIATE
DOWN
DIFD --- --- !DIFD 168
015 TEN-MS TIMER TIMH --- --- --- 221
016 WORD SHIFT WSFT @WSFT --- --- 313
017 ASYNCHRONOUS
SHIFT REGISTER
ASFT @ASFT --- --- 311
019 MULTIPLE COMPARE MCMP @MCMP --- --- 267
020 COMPARE CMP --- --- !CMP 261
021 MOVE MOV @MOV --- !MOV 283
022 MOVE NOT MVN @MVN --- --- 286
023 BCD TO BINARY BIN @BIN --- --- 382
024 BINARY TO BCD BCD @BCD --- --- 384
025 ARITHMETIC SHIFT
LEFT
ASL @ASL --- --- 315
026 ARITHMETIC SHIFT
RIGHT
ASR @ASR --- --- 317
027 ROTATE LEFT ROL @ROL --- --- 319
028 ROTATE RIGHT ROR @ROR --- --- 323
029 COMPLEMENT COM --- --- --- 446
034 LOGICAL AND ANDW @ANDW --- --- 438
035 LOGICAL OR ORW @ORW --- --- 440
