3. Instructions
356
CS/CJ/NSJ Series Instructions Reference Manual (W474)
+BC/+BCL
Applicable Program Areas
Operands
z Operand Specifications
Instruction Mnemonic Variations
Function
code
Function
BCD ADD WITH CARRY +BC @+BC 406
Adds 4-digit (single-word) BCD data and/or con-
stants with the Carry Flag (CY).
DOUBLE BCD ADD WITH
CARRY
+BCL @+BCL 407
Adds 8-digit (double-word) BCD data and/or con-
stants with the Carry Flag (CY).
Symbol
+BC +BCL
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or
transition programs
Usage OK OK OK OK OK OK
Operand Description
Data type Size
+BC +BCL +BC +BCL
Au
+BC: Augend word
+BCL: First augend word
WORD DWORD 1 2
Ad
+BC: Addend word
+BCL: First addend word
WORD DWORD 1 2
R
+BC: Result word
+BCL: First result word
WORD DWORD 1 2
Area
Word addresses
Indirect
DM/EM
addresses
Con-
stants
Registers
TK CF
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
+BC
Au, Ad
OK OK OK OK OK OK OK OK OK OK
OK
OK --- OK --- --- --- ---
R ---
+BCL
Au, Ad
OK OK OK OK OK OK OK OK OK OK
OK
--- --- OK --- --- --- ---
R ---
+BC(406)
R
Au
Ad
Au: Augend word
Ad: Addend word
R: Result word
+BCL(407)
R
Au
Ad
Au: 1st augend word
Ad: 1st addend word
R: 1st result word
