3. Instructions
CS/CJ/NSJ Series Instructions Reference Manual (W474)
High-speed Counter/Pulse Output Instructions
3
PLS2
PLS2
Applicable Program Areas
Operands
P: Port Specifier
Instruction Mnemonic Variations
Function
code
Function
PULSE OUTPUT PLS2 @PLS2 887
PLS2(887) outputs a specified number of pulses
to the specified port. Pulse output starts at a spec-
ified startup frequency, accelerates to the target
frequency at a specified acceleration rate, decel-
erates at the specified deceleration rate, and stops
at approximately the same frequency as the star-
tup frequency.
Symbol
PLS2
Area
Function block
definitions
Block program areas Step program areas Subroutines Interrupt tasks
SFC action or transition
programs
Usage OK OK OK OK OK OK
Operand Description Data type Size
P Port specifier --- 1
M Output mode --- 1
S First word of settings table WORD 6
F First word of starting frequency UDINT 2
P Port
0000 hex Pulse output 0
0001 hex Pulse output 1
0002 hex Pulse output 2 (CJ2M only)
0003 hex Pulse output 3 (CJ2M only)
P: Port specifier
M: Output mode
S: First word of settings table
F: First word of starting frequency
PLS2(887)
P
M
S
F
To Next Page
