Omron CJ - INSTRUCTIONS - Page 104

66
CS/CJ/NSJ Series Instructions Reference Manual (W474)
2. Summary of Instructions
DATA DECODER
MLPX
@MLPX
076
Output
Required
391
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
MLPX(076)
S
C
R
S: Source word
C: Control word
R: 1st result word
C
R
R+1
C
R+1
R+14
R+15
R+16
R+17
R+30
R+31
Reads the numerical value in the specified digit (or byte) in the source
word, turns ON the corresponding bit in the result word (or 16-word
range), and turns OFF all other bits in the result word (or 16-word
range).
l
=1 (Convert 2 digits.)
4-to-16 bit conversion
n=2 (Start with second digit.)
4-to-16 bit decoding
(Bit m of R is turned ON.)
8-to-256 bit conversion
l=1 (Convert 2 bytes.)
n=1 (Start with first byte.)
8-to-256 bit decoding
(Bit m of R to R+15 is turned ON.)
Two 16-word ranges
are used when l
specifies 2 bytes.
