Omron CJ - INSTRUCTIONS - Page 107

69
CS/CJ/NSJ Series Instructions Reference Manual (W474)
2. Summary of Instructions
2-2 Instruction Functions
2
2-2-10 Conversion Instructions
SIGNED BCD TO
BINARY
BINS
@BINS
470
Output
Required
414
DOUBLE
SIGNED BCD TO
BINARY
BISL
@BISL
472
Output
Required
414
SIGNED BINARY
TO BCD
BCDS
@BCDS
471
Output
Required
419
DOUBLE
SIGNED BINARY
TO BCD
BDSL
@BDSL
473
Output
Required
419
GRAY CODE
CONVERSION
GRY
474
(CS/CJ-series
Unit Ver. 2.0 or
later and CJ2 CPU
Units only, includ-
ing CS1-H, CJ1-H,
and CJ1M CPU
Units from lot
number 030201
and later)
Converts the Gray code data in the specified word to binary, BCD, or
angle (°) data at the specified resolution.
Output
Required
423
GRAY CODE TO
BINARY CON-
VERT
GRAY_BIN
@GRAY_BIN
478
(CJ2 only)
Converts the specified word of gray code to one word of binary data. Output
Required
428
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
BINS(470)
C
S
D
C: Control word
S: Source word
D: Destination
word
Signed BCD
Converts one word of signed BCD data to one word of signed binary
data.
Signed BCD format
specified in C
Signed binary
BISL(472)
C
S
D
C: Control word
S: 1st source
word
D: 1st destination
word
Signed BCD
Signed BCD
Signed binary
Signed binary
Signed BCD format
specified in C
Converts double signed BCD data to double signed binary data.
BCDS(471)
C
S
D
C: Control word
S: Source word
D: Destination
word
Signed BCD
Converts one word of signed binary data to one word of signed BCD
data.
Signed BCD format
specified in C
Signed binary
BDSL(473)
C
S
D
C: Control word
S: 1st source
word
D: 1st destination
word
Signed BCD
Signed BCD
Signed BCD format
specified in C
Signed binary
Signed binary
Converts double signed binary data to double signed BCD data.
GRY (474)
C
S
D
C: Control word
S: Source word
D: 1st destination
word
GRAY_BIN(478)
S
D
S: Source
(gray code)
D: Destination
(binary data)
