3. Instructions
1038
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Setting the Monitoring Time with the Teaching Function
The monitoring time can be set automatically with the teaching function when a word address has been
specified for T.
To start the teaching function, turn ON A598.00 (the FPD Teaching Bit). While A598.00 is ON,
FPD(269) measures how long it takes for the diagnostic output (CIO 200.00) to go ON after the
execution condition (CIO 300.00) goes ON. If the measured time exceeds the monitoring time in T, the
measured time is multiplied by 1.5 and that value is stored in T as the new monitoring time.
t
s
: Initial setting in T
t
a
: Measured time
t’
s
: New setting in T after teaching
(When t
a
> t
s
, t’
s
= t
a
× 1.5)
R+1: D301
R: D300
R+2: D302
R+3: D303
R+4: D304
R+5: D305
R+6: D306
R+7: D307
R+8: D308
R+9: D309
30
30
30
2D
54
25
25
00
31
30
30
30
25
F4
00
00
R+10: D310
00
00
FAL number = 10
Diagnostic output mode = 8 (bit address and message output)
Bit Address Found Flag
1: Bit address found
Input type
0: Normally open
Contains bit address in ASCII.
(100.00 is converted to ASCII.)
User-set FAL error message output to a
Peripheral Device by the time monitoring
function. The Peripheral Display will show
the following: 100.00-0 ERROR.
Not used.
T
R
The teaching function
can set the monitoring
time in T automatically.
Execution
condition
Diagnostic output
300.00
200.00
D200
D300
A598.00
CIO 300.00
CIO 200.00
t'
s
(t
a
× 1.5)
No error generated.
Measured time: t
a
Teaching
FPD Teaching Bit
Execution condition
Diagnostic output
