CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-1 CJ2 CPU Unit Instruction Execution Times and Number of Steps
4
4-1-11 Logic Instructions
4-1-11 Logic Instructions
GRAY CODE CONVERSION GRY 4 26.5 49.1 8-bit binary
27.6 51.1 8-bit BCD
30.9 57.2 8-bit angle
35.3 66.0 15-bit binary
36.3 68.0 15-bit BCD
39.6 74.0 15-bit angle
GRAY CODE TO BINARY
CONVERT
GRAY_BIN 3 0.1 0.3 ---
DOUBLE GRAY CODE TO
BINARY CONVERT
GRAY_BINL 3 to 4 0.1 0.4 ---
DOUBLE GRAY CODE TO
BINARY CONVERT
BIN_GRAY 3 0.1 0.3 ---
DOUBLE BINARY TO GRAY
CODE CONVERT
BIN_GRAYL 3 to 4 0.1 0.4 ---
FOUR-DIGIT NUMBER TO
ASCII
STR4 3 8.4 14.2 ---
EIGHT-DIGIT NUMBER TO
ASCII
STR8 3 to 4 10.2 16.4 ---
SIXTEEN-DIGIT NUMBER
TO ASCII
STR16 3 15.8 28.2 ---
ASCII TO FOUR-DIGIT NUM-
BER
NUM4 3 to 4 10.5 18.5 ---
ASCII TO EIGHT-DIGIT NUM-
BER
NUM8 3 14.8 27.1 ---
ASCII TO SIXTEEN-DIGIT
NUMBER
NUM16 3 27.4 52.0 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
LOGICAL AND ANDW 4 0.14 0.340 ---
DOUBLE LOGICAL AND ANDL 4 to 6 0.26 0.640 ---
LOGICAL OR ORW 4 0.18 0.340 ---
DOUBLE LOGICAL OR ORWL 4 to 6 0.26 0.640 ---
EXCLUSIVE OR XORW 4 0.18 0.340 ---
DOUBLE EXCLUSIVE OR XORL 4 to 6 0.26 0.640 ---
EXCLUSIVE NOR XNRW 4 0.18 0.340 ---
DOUBLE EXCLUSIVE NOR XNRL 4 to 6 0.26 0.640 ---
COMPLEMENT COM 2 0.18 0.240 ---
DOUBLE COMPLEMENT COML 2 0.32 0.440 ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CJ2H
CPU6@(-EIP)
CJ2M CPU@@
