CS/CJ/NSJ Series Instructions Reference Manual (W474)
4. Instruction Execution Times and Number of Steps
4-3 CS-series Instruction Execution Times and Number of Steps
4
4-3-10 Conversion Instructions
SIGNED BCD TO
BINARY
BINS 4 8.0 8.3 12.1 12.1 Data format set-
ting No. 0
8.0 8.3 12.1 12.1 Data format set-
ting No. 1
8.3 8.6 12.7 12.7 Data format set-
ting No. 2
8.5 8.8 13.0 13.0 Data format set-
ting No. 3
DOUBLE SIGNED BCD
TO BINARY
BISL 4 to 5 9.2 9.6 13.6 13.6 Data format set-
ting No. 0
9.2 9.6 13.7 13.7 Data format set-
ting No. 1
9.5 9.9 14.2 14.2 Data format set-
ting No. 2
9.6 10.0 14.4 14.4 Data format set-
ting No. 3
SIGNED BINARY TO
BCD
BCDS 4 6.6 6.9 10.6 10.6 Data format set-
ting No. 0
6.7 7.0 10.8 10.8 Data format set-
ting No. 1
6.8 7.1 10.9 10.9 Data format set-
ting No. 2
7.2 7.5 11.5 11.5 Data format set-
ting No. 3
DOUBLE SIGNED
BINARY TO BCD
BDSL 4 to 5 8.1 8.4 11.6 11.6 Data format set-
ting No. 0
8.2 8.6 11.8 11.8 Data format set-
ting No. 1
8.3 8.7 12.0 12.0 Data format set-
ting No. 2
8.8 9.2 12.5 12.5 Data format set-
ting No. 3
GRAY CODE CONVER-
SION
GRY 4 46.9 72.1 --- --- 8-bit binary
49.6 75.2 --- --- 8-bit BCD
57.7 87.7 --- --- 8-bit angle
61.8 96.7 --- --- 15-bit binary
64.5 99.6 --- --- 15-bit BCD
72.8 112.4 --- --- 15-bit angle
52.3 87.2 --- --- 360° binary
55.1 90.4 --- --- 360° BCD
64.8 98.5 --- --- 360° angle
FOUR-DIGIT NUMBER
TO ASCII
STR4 3 13.79 20.24 --- ---
EIGHT-DIGIT NUMBER
TO ASCII
STR8 3 to 4 18.82 27.44 --- ---
SIXTEEN-DIGIT NUM-
BER TO ASCII
STR16 3 30.54 44.41 --- ---
ASCII TO FOUR-DIGIT
NUMBER
NUM4 3 to 4 18.46 27.27 --- ---
ASCII TO EIGHT-DIGIT
NUMBER
NUM8 3 27.27 40.29 --- ---
ASCII TO SIXTEEN-
DIGIT NUMBER
NUM16 3 52.31 78.25 --- ---
Instruction Mnemonic Length
(steps)
ON execution time (µs) Conditions
CS1H
CPU6@H
CS1G
CPU4@H
CS1H
CPU6@
CS1G
CPU4@
