1239
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
Appendix A List of Instructions by Function Code
App
735 CLOCK ADJUSTMENT DATE @DATE --- --- 1013
750 GLOBAL SUBROU-
TINE CALL
GSBS @GSBS --- --- 699
751 GLOBAL SUBROU-
TINE ENTRY
GSBN --- --- --- 705
752 GLOBAL SUBROU-
TINE RETURN
GRET --- --- --- 705
780 READ SET TIMER TSR @TSR --- --- 1136
781 SET STEP TIMER TSW @TSW --- --- 1136
784 STEP ACTIVATE SA @SA --- --- 1134
785 STEP DEACTIVATE SE @SE --- --- 1134
789 SFC ON SFCON --- --- --- 1138
790 SFC OFF SFCOFF --- --- --- 1138
791 SFC PAUSE WITH NO
RESET
SFCPRN --- --- --- 1140
793 SFC PAUSE WITH
RESET
SFCPR --- --- --- 1140
801 BLOCK PROGRAM
END
BEND --- --- --- 1060
802 IF NOT IF NOT (oper-
and)
--- --- --- 1066
802 IF IF (input condi-
tion)
--- --- --- 1066
802 IF IF (operand) --- --- --- 1066
803 ELSE ELSE --- --- --- 1066
804 IF END IEND --- --- --- 1066
805 ONE CYCLE AND
WAIT NOT
WAIT NOT
(operand)
--- --- --- 1069
805 ONE CYCLE AND
WAIT
WAIT (input
condition)
--- --- --- 1069
805 ONE CYCLE AND
WAIT
WAIT (operand) --- --- --- 1069
806 CONDITIONAL BLOCK
EXIT NOT
EXIT NOT
(operand)
--- --- --- 1064
806 CONDITIONAL BLOCK
EXIT
EXIT (input con-
dition)
--- --- --- 1064
806 CONDITIONAL BLOCK
EXIT
EXIT (operand) --- --- --- 1064
809 LOOP LOOP --- --- --- 1080
810 LOOP END NOT LEND NOT
(operand)
--- --- --- 1080
810 LOOP END LEND (input
condition)
--- --- --- 1080
810 LOOP END LEND (oper-
and)
--- --- --- 1080
811 BLOCK PROGRAM
PAU SE
BPPS --- --- --- 1062
812 BLOCK PROGRAM
RESTART
BPRS --- --- --- 1062
813 HUNDRED-MS TIMER
WAIT
TIMW --- --- --- 1072
814 COUNTER WAIT CNTW --- --- --- 1075
815 TEN-MS TIMER WAIT TMHW --- --- --- 1077
816 HUNDRED-MS TIMER
WAIT
TIMWX --- --- --- 1072
817 TEN-MS TIMER WAIT TMHWX --- --- --- 1077
818 COUNTER WAIT CNTWX --- --- --- 1075
820 TASK ON TKON @TKON --- --- 1112
821 TASK OFF TKOF @TKOF --- --- 1112
840 EXPONENTIAL
POWER
PWR @PWR --- --- 500
841 DOUBLE FLOATING
TO 16-BIT BINARY
FIXD @FIXD --- --- 521
Function code Instruction Mnemonic Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
