CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
Appendix B Alphabetical List of Instructions by Mnemonic
App
B
ASFT ASYNCHRONOUS
SHIFT REGISTER
017 @ASFT --- --- 311
ASIN ARC SINE 463 @ASIN --- --- 491
ASIND DOUBLE ARC SINE 854 @ASIND --- --- 535
ASL ARITHMETIC SHIFT
LEFT
025 @ASL --- --- 315
ASLL DOUBLE SHIFT LEFT 570 @ASLL --- --- 315
ASR ARITHMETIC SHIFT
RIGHT
026 @ASR --- --- 317
ASRL DOUBLE SHIFT
RIGHT
571 @ASRL --- --- 317
ATAN ARC TANGENT 465 @ATAN --- --- 491
ATAND DOUBLE ARC TAN-
GENT
856 @ATAND --- --- 535
AVG AVERAGE 195 --- --- --- 683
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
BAND DEAD BAND CON-
TROL
681 @BAND --- --- 660
BCD BINARY TO BCD 024 @BCD --- --- 384
BCDL DOUBLE BINARY TO
BCD
059 @BCDL --- --- 384
BCDS SIGNED BINARY TO
BCD
471 @BCDS --- --- 419
BCMP UNSIGNED BLOCK
COMPARE
068 @BCMP --- --- 271
BCMP2 EXPANDED BLOCK
COMPARE
502 @BCMP2 --- --- 273
BCNT BIT COUNTER 067 @BCNT --- --- 465
BCNTC BIT COUNTER 621 @BCNTC --- --- 1128
BDSL DOUBLE SIGNED
BINARY TO BCD
473 @BDSL --- --- 419
BEND BLOCK PROGRAM
END
801 --- --- --- 1060
BIN BCD TO BINARY 023 @BIN --- --- 382
BIN_GRAY BINARY TO GRAY
CODE CONVERT
480 @BIN_GRAY --- --- 430
BIN_GRAYL DOUBLE BINARY TO
GRAY CODE CON-
VERT
481 @BIN_GRAYL --- --- 430
BINL DOUBLE BCD TO
DOUBLE BINARY
058 @BINL --- --- 382
BINS SIGNED BCD TO
BINARY
470 @BINS --- --- 414
BISL DOUBLE SIGNED
BCD TO BINARY
472 @BISL --- --- 414
BPPS BLOCK PROGRAM
PAUS E
811 --- --- --- 1062
BPRG BLOCK PROGRAM
BEGIN
096 --- --- --- 1060
BPRS BLOCK PROGRAM
RESTART
812 --- --- --- 1062
BREAK BREAK LOOP 514 --- --- --- 208
BSET BLOCK SET 071 @BSET --- --- 296
Mnemonic Instruction Function code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
