1252
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Appendices
P
R
OR <=S OR SIGNED LESS
THAN OR EQUAL
317 --- --- --- 253
OR <=SL OR DOUBLE SIGNED
LESS THAN OR
EQUAL
318 --- --- --- 253
OR >= OR GREATER THAN
OR EQUAL
325 --- --- --- 253
OR >=$ OR STRING GREATER
THAN OR EQUALS
675 --- --- --- 1107
OR >=D OR DOUBLE FLOAT-
ING GREATER THAN
OR EQUAL
340 --- --- --- 546
OR >=DT OR TIME GREATER
THAN OR EQUAL
346 --- --- --- 257
OR >=F OR FLOATING
GREATER THAN OR
EQUAL
334 --- --- --- 502
OR >=L OR DOUBLE
GREATER THAN OR
EQUAL
326 --- --- --- 253
OR >=S OR SIGNED
GREATER THAN OR
EQUAL
327 --- --- --- 253
OR >=SL OR DOUBLE SIGNED
GREATER THAN OR
EQUAL
328 --- --- --- 253
ORG ORIGIN SEARCH 889 @ORG --- --- 774
ORW LOGICAL OR 035 @ORW --- --- 440
ORWL DOUBLE LOGICAL OR 611 @ORWL --- --- 440
OUT OUTPUT --- --- --- !OUT 158
OUTB SINGLE BIT OUTPUT 534 @OUTB --- !OUTB 176
OUT NOT OUTPUT NOT --- --- --- !OUT NOT 158
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
PID PID CONTROL 190 --- --- --- 640
PIDAT PID CONTROL WITH
AUTOTUNING
191 --- --- --- 651
PMCR PROTOCOL MACRO 260 @PMCR --- --- 847
PMCR2 PROTOCOL MACRO 2 264 @PMCR2 --- --- 898
PRV HIGH-SPEED
COUNTER PV READ
881 @PRV --- --- 736
PRV2 COUNTER FRE-
QUENCY CONVERT
883 @PRV2 --- --- 742
PULS SET PULSES 886 @PULS --- --- 755
PLS2 PULSE OUTPUT 887 @PLS2 --- --- 757
PUSH PUSH ONTO STACK 632 @PUSH --- --- 557
PWM PULSE WITH VARI-
ABLE DUTY FACTOR
891 @PWM --- --- 777
PWR EXPONENTIAL
POWER
840 @PWR --- --- 500
PWRD DOUBLE EXPONEN-
TIAL POWER
860 @PWRD --- --- 544
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
RAD DEGREES TO RADI-
ANS
458 @RAD --- --- 480
RADD DOUBLE DEGREES
TO RADIANS
849 @RADD --- --- 528
RECV NETWORK RECEIVE 098 @RECV --- --- 935
Mnemonic Instruction FUN code Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
To Next Page
