119
CS/CJ/NSJ Series Instructions Reference Manual (W474)
2. Summary of Instructions
2-2 Instruction Functions
2
2-2-31 Block Programming Instructions
COUNTER WAIT
CNTW
814
(BCD)
CNTWX
818
(Binary)
(CJ2, CS1-H,
CJ1-H, CJ1M, or
CS1D only)
CNTW(814)
N
SV
N: Counter
number
SV: Set value
I: Count input
Block program
Required
1075
CNTWX(818)
N
SV
N: Counter
number
SV: Set value
I: Count input
TEN-MS TIMER
WAIT
TMHW
815
(BCD)
TMHWX
817
(Binary)
(CJ2, CS1-H,
CJ1-H, CJ1M, or
CS1D only)
TMHW(815)
N
SV
N: Timer number
SV: Set value
Block program
Required
1077
TMHWX(817)
N
SV
N: Timer number
SV: Set value
LOOP
LOOP
809
--- Block program
Required
1080
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
C
Time elapsed.
Delays execution of the rest of the block program until the specified count
has been achieved. Execution will be continued from the next instruction
after CNTW(814)/CNTWX(818) when the counter counts out.
SV: 0 to 9,999 times for BCD and
0 to 65,535 times for binary
"C"
executed.
"C"
executed.
"C" executed.
"B" executed.
SV
preset.
"A"
executed.
C
BEND
Time elapsed.
Delays execution of the rest of the block program until the specified
time has elapsed. Execution will be continued from the next
instruction after TMHW(815)/TMHWX(818) when the timer times out.
SV: 0 to 99.99 s for BCD
and 0 to 655.35 s for binary
"A"
executed.
SV
preset.
"B" executed.
"C" executed.
Loop repeated
Execution condition
LOOP(809) designates the beginning of the loop program.
Execution
condition
ON
Execution
condition
OFF
Execution
condition
OFF
Execution
condition
OFF
