z Operation of @++B(594)/@++BL(595)
The up-differentiated variation is used in the following example, so the content of D100 will be
incremented by 1 only when CIO 0.00 has gone from OFF to ON.
The up-differentiated variation is used in the following example, so the BCD content of D101 and D100
will be incremented by 1 only when CIO 0.00 has gone from OFF to ON.
@++B
D100 D100Wd: Wd:
Incremented only for
up-differentiation.
D100
0.00
@++BL
D101 D100 D101 D100
Increment Increment
Wd+1: Wd: Wd+1: Wd:
: Execution of @++B(594)/@++BL(595)
Incremented only for
up-differentiation.
D100
0.00
