413
3. Instructions
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Conversion Instructions
3
COLM
Flags
Function
Example Programming
When CIO 0.00 is ON in the following example, COLM(064) copies the 16 bits in D200 (bits 00 through
15) to bit 5 in D100 through D115.
Name Label Operation
Error Flag ER • ON if N is not within the specified range of 0000 to 000F.
• OFF in all other cases.
Equal Flag = • ON if bit N is 0 in all 16 words D to D+15 after execution.
• OFF in all other cases.
COLM(064) copies the 16 bits from S to the
16 bits with bit number N in the 16-word range
D to D+15. Bit m of S is copied to bit N of
D+m, i.e., bit 00 of S is copied to bit N of D
and bit 15 of S is copied to bit N of D+15.
Data other than the specified bits of the
conversion result output word are held (kept
the same as before).
0
00001110001 00001
15 00
D
11010010011 10001
D+1
00011011001 00111
D+2
.
.
.
.
.
.
.
.
.
.
0 1 1 1 0 0 0 1 100 0 1 0 10
D+15
10000011000 00111
D+3
0 1 1
S
1
15 00
. . . . . .
.
.
.
Bit Bit
Bi
Bit Bit
S: D200
D: D100
D101
D102
D115
0.00
D200
D100
