3. Instructions
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Floating-point Math Instructions
3
+F, –F, *F, /F
Flags
Function
The data specified in Au/Mi/Md/Dd and the data specified in AD/Su/Mr/Dr are added (+F), subtracted
(-F), multiplied (*F), or divided (/F) as single-precision floating-point data (32 bits: IEEE754) and
output to D+1, D.
z +F
z -F
z *F
Name Label Operation
Error Flag ER ON if Au, AD, Mi, Su, Md, Dd is not recognized as floating-point data.
+F
• ON if the augend or addend data is not a number (NaN).
• ON if +∞ and –∞ are added.
-F
• ON if the minuend or subtrahend is not a number (NaN).
• ON if +∞ is subtracted from +∞.
• ON if –∞ is subtracted from –∞.
*F
• ON if the multiplicand or multiplier is not a number (NaN).
• ON if +∞ and 0 are multiplied.
• ON if –∞ and 0 are multiplied.
/F
• ON if the dividend or divisor is not a number (NaN).
• ON if the dividend and divisor are both 0.
• ON if the dividend and divisor are both +∞ or –∞.
OFF in all other cases.
Equals Flag = • ON if both the exponent and mantissa of the result are 0.
• OFF in all other cases.
Overflow Flag OF • ON if the absolute value of the result is too large to be expressed as a 32-bit floating-point value.
• OFF in all other cases.
Underflow Flag UF • ON if the absolute value of the result is too small to be expressed as a 32-bit floating-point value.
• OFF in all other cases.
Negative Flag N • ON if the result is negative.
• OFF in all other cases.
R+1 R
+
Au
Au+1
Ad
Ad+1
Result (floating-point data, 32 bits)
Augend (floating-point data, 32 bits)
Addend (floating-point data, 32 bits)
R+1
R
–
Mi
Mi+1
Su
Su+1
Result (floating-point data, 32 bits)
Subtrahend (floating-point data, 32 bits)
Minuend (floating-point data, 32 bits)
R+1
R
Md
Multiplicand (floating-point data, 32 bits)
Md+1
Mr
Multiplier (floating-point data, 32 bits)
Mr+1
Result (floating-point data, 32 bits)
×
