CS/CJ/NSJ Series Instructions Reference Manual (W474)
2. Summary of Instructions
2-2 Instruction Functions
2
2-2-2 Sequence Output Instructions
SINGLE BIT
RESET (CJ2,
CS1-H, CJ1-H,
CJ1M, or CS1D
only)
RSTB
@RSTB
!RSTB
*1
!@RSTB
*1
RSTB(533) turns OFF the specified bit in the specified word when the
execution condition is ON.
Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a
DM or EM word.
Output
Required
174
SINGLE BIT
OUTPUT (CJ2,
CS1-H, CJ1-H,
CJ1M, or CS1D
only)
OUTB
@OUTB
!OUTB
*1
OUTB(534) outputs the result (execution condition) of the logical pro-
cessing to the specified bit.
Unlike the OUT instruction, OUTB(534) can be used to control a bit in a
DM or EM word.
Output
Required
176
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
Page
RSTB(533)
D
N
D: Word address
N: Bit number
OUTB(534)
D
N
D: Word address
N: Bit number
To Next Page
