3. Instructions
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Basic I/O Unit Instructions
3
7SEG
• Converting 8 digits
C: Control Data
The value of C (0000 to 0007 hex) indicates the number of digits of source data and the logic for the
Input and Output Units, as shown in the following table. (The logic refers to the transistor output's NPN
or PNP logic.)
D: System Word
Specifies a work word used by the instruction. This word cannot be used in any other application.
z Operand Specifications
Flags
Function
7SEG(214) reads the source data, converts it to 7-segment display data, and outputs that data (as
leftmost 4 digits D0 to D3, rightmost 4 digits D0 to D3, latch output signals LE0 to LE3) to the 7-
segment display connected to the output indicated by O. The value of C indicates the number of digits
of source data (either 4-digit or 8-digit) and the logic for the Input and Output Units.
7SEG(214) displays the 4-digit or 8-digit data in 12 cycles, and then starts over and continues
displaying the data.
Source data Display's data input logic Display's latch input logic C
4 digits (S) Same as Output Unit Same as Output Unit 0000
Different from Output Unit 0001
Different from Output Unit Same as Output Unit 0002
Different from Output Unit 0003
8 digits (S, S+1) Same as Output Unit Same as Output Unit 0004
Different from Output Unit 0005
Different from Output Unit Same as Output Unit 0006
Different from Output Unit 0007
Area
Word addresses
Indirect DM/EM
addresses
Con-
stants
Registers Flags
Pulse
bits
TR
bits
CIO WR HR AR T C DM EM
@DM
@EM
*DM
*EM
DR IR
Indirect
using IR
TK CF
S
OK OK OK OK OK OK OK OK OK OK ---
---
---
OK
--- --- --- ---
O OK
C --- --- --- --- --- --- --- --- --- --- OK --- ---
D OKOKOKOKOKOKOKOK OK OK --- OK OK
Name Label Operation
Error Flag P_ER OFF
0123456789101112131415
−−−
O
D0
D1
D2
D3
LE3
LE2
LE1
LE0
D0
D1
D2
D3
Leftmost 4-digit data output
Rightmost 4-digit data output
Latch outputs
One Round Flag
D
15 0
System word
(Cannot be accessed by the user.)
