Manipulating Files Section 5-2
Note Data from the Units and Boards listed above will be automatically backed up
for the simple backup operation. There is no setting available to include or
exclude them. If a Programming Console is used, however, operations are
supported individually for the user program area, parameter area, and I/O
memory areas. Refer to the Programming Console Operation Manual (W314)
for details.
Procedure
The procedure for the simple backup operation is the same regardless of
whether or not data is being backed up from specific Units and Boards
(including writing, reading, and comparing).
■ Backing Up Data
1,2,3... 1. Turn ON pin 7 on the CPU Unit’s DIP switch.
2. Press and hold the Memory Card Power Supply Switch for three seconds.
CompoNet Units CS1W-CRM21
CJ1W-CRM21
• Registration tables
• Software settings
• Network parameters
• Slave parameters
3.5 Kbytes
Customizable
Counter Units
CS1W-HIO01-V1
CS1W-HCP22-V1
CS1W-HCA22-V1
CS1W-HCA12-V1
• User program
• General-purpose read-
only DM
• Unit function setting area
• Information on expan-
sion instructions
• Ladder library
64 Kbytes
Motion Control
Units
CS1W-MCH71
CJ1W-MCH71
• Positioning data
• System parameters
• G language programs
8,192 Kbytes
CS1W-MC221-V1
CS1W-MC421-V1
142 Kbytes
Position Control
Units
CJ1W-NCF71 • Common parameters
• Individual axis parame-
ters
64 Kbytes
Position Control
Units
CS1W-
NC113/133/213/2
33/413/433
Ver. 2.0 or later
CJ1W-
NC113/133/213/2
33/413/433
Ver. 2.0 or later
• Axis parameters
• Sequence data
• Speed data
• Acceleration/decelera-
tion time data
• Dual timer data
• Zone data
7 Kbytes
Loop Control
Board
CS1W-LCB01
CS1W-LCB05
• Function block data
• Block connection data
1,563 Kbytes
Unit/Board Model numbers Data backed up for
simple backup when
used with CS1-H/CJ1-H
CPU Unit
Data capacity
used in Memory
Card for simple
backup
