Omron CJ2M-CPU Series User Manual

7 High-speed Counters
7-40
CJ2M CPU Unit Pulse I/O Module User’s Manual
High-speed
Counter 3 Range
Comparison Con-
dition 1 In-range
Flag
A321.00 These flags indicate whether the
PV is within any of the eight ranges
when high-speed counter 3 is being
operated in range-comparison
mode with upper and lower limits.
The In-range Flags, however, will be
ON whenever the comparison value
is within the range regardless of the
whether the high-speed counter is
set to execute the interrupt task
when the range is entered or left.
OFF: Not in range
ON: In range
Read • Cleared when power is
turned ON.
• Cleared when opera-
tion starts.
• Refreshed each cycle
during overseeing pro-
cess.
• Refreshed when
PRV(881) instruction is
executed for the corre-
sponding counter.
• Refreshed when
INI(880) instruction is
executed to change PV
or ring counter maxi-
mum value.
•Reset
High-speed
Counter 3 Range
Comparison Con-
dition 2 In-range
Flag
A321.01
High-speed
Counter 3 Range
Comparison Con-
dition 3 In-range
Flag
A321.02
High-speed
Counter 3 Range
Comparison Con-
dition 4 In-range
Flag
A321.03
High-speed
Counter 3 Range
Comparison Con-
dition 5 In-range
Flag
A321.04
High-speed
Counter 3 Range
Comparison Con-
dition 6 In-range
Flag
A321.05
High-speed
Counter 3 Range
Comparison Con-
dition 7 In-range
Flag
A321.06
High-speed
Counter 3 Range
Comparison Con-
dition 8 In-range
Flag
A321.07
High-speed
Counter 3 Compar-
ison In-progress
Flag
A321.08 This flag indicates whether a com-
parison operation is being executed
for high-speed counter 3.
OFF: Stopped.
ON: Being executed.
Read • Cleared when power is
turned ON.
• Cleared when starting
operation.
• Refreshed when start-
ing/stopping compari-
son.
High-speed
Counter 3 Over-
flow/Underflow
Flag
A321.09 This flag indicates when an over-
flow or underflow has occurred in
the high-speed counter 3 PV. (Used
only when the counting mode is set
to Linear Mode.)
OFF: Normal
ON: Overflow or underflow
Read • Cleared when power is
turned ON.
• Cleared when opera-
tion starts.
• Cleared when the PV is
changed.
• Refreshed when an
overflow or underflow
occurs.
Name Word/Bit Function Read/Write Refresh timing

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
