Omron CJ2M-CPU Series User Manual

4-5
4 Normal I/O
CJ2M CPU Unit Pulse I/O Module User’s Manual
4-2 Normal Outputs
4
4-2-1 Overview
4-2 Normal Outputs
Normal outputs are used to output standard output signals. The output point is refreshed when the allo-
cated bit goes ON or OFF. Normal outputs are allocated to bits 00 to 05 of CIO 2961 and CIO 2963.
4-2-1 Overview
4-2-2 Flow of Operation
1
• Functions are assigned to output terminals when an
instruction (such as OUT, ORG(889), or PWM(891)) is
executed for an output bit.
2
• Execute the OUT instruction or other instructions.
• Use !OUT instructions and other immediate refreshing
version of instructions when immediate refreshing is
required.
Note: Immediate refreshing cannot be performed by the
IORF(097) instruction.
Determine the normal outputs to use.
Write the ladder program.

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
