Omron CJ2M-CPU Series User Manual

12
CJ2M CPU Unit Pulse I/O Module User’s Manual
Section 9 PWM Outputs
9-1 PWM Outputs (Variable Duty Ratio Pulse Outputs).............................................................. 9-2
9-1-1 Overview .....................................................................................................................................9-2
9-1-2 Application Procedure ................................................................................................................. 9-3
9-1-3 Wiring..........................................................................................................................................9-4
9-1-4 Ladder Program Example ........................................................................................................... 9-5
Appendices
A-1 Flag Operations during Pulse Output....................................................................................A-2
A-2 Combinations of Pulse Control Instructions .......................................................................A-3
A-3 Comparison to CJ1M Built-in I/O Functions .........................................................................A-7
A-4 Performance Information ......................................................................................................A-10
A-4-1 Interrupt Input Response Time .................................................................................................A-10
A-4-2 Pulse Output Start Time............................................................................................................A-11
A-4-3 Response Times of Pulse Output Changes ..............................................................................A-11
Index................................................................................................................ Index-1
Revision History........................................................................................Revision-1

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
