Omron CJ2M-CPU Series User Manual

5 Quick-response Inputs
5-4
CJ2M CPU Unit Pulse I/O Module User’s Manual
Interrupt Input and Quick-response Input Detailed Settings
Note The power supply must be restarted after the PLC Setup is transferred in order to validate the quick-
response input settings.
Pulse I/O
Module No.
Input Operation
Corresponding bit
address
0 (on the right) IN00 Select Quick for IN00
to IN03 or IN10 to
IN13.
CIO 2960.00
IN01 CIO 2960.01
IN02 CIO 2960.02
IN03 CIO 2960.03
1 (on the left) IN10 CIO 2962.00
IN11 CIO 2962.01
IN12 CIO 2962.02
IN13 CIO 2962.03

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
