13
PROFIBUS-DP Master Unit
Section 1-3
External Dimensions
I/O Data
Number of I/O module definitions 4000 max. over all configured Slave stations
Number of I/O data supported by Master Up to 244 bytes input and 244 bytes output max. per Slave station
(defined by Slave station)
Total sum of all I/O Data must not exceed 7168 words
Number of diagnostics data supported by
Master
Up to 244 bytes of diagnostics max. per Slave station
Diagnostic data is collected at the Unit, and can be obtained from
the Unit using FINS messaging
Item Specification
101
3
94
25
11
(UNIT: mm)
RUN
RUN
ERC
ERC
BST
BST
BF
BF
ISOM
ISOM
130
35
PRM21 CS
CS
UNIT
No.
F
E
D
C
B
A
9
8
7
6
5
4
3
2
1
0
RUN
RUN
ERC
ERC
BST
BST
BF
BF
ERH
ERH
PRM
PRM
COMM
COMM
BUS
CS1W-PRM21
ERC
RUN
BF
PRM21
COMM
BST
ERH
PRM
31
90
CJ1W-PRM21
NO.
UNIT
BUS
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
65
(UNIT: mm)
54
25
11
3
