19
CX-Profibus Configurator
Section 1-4
CS1W-PRM21 / CJ1W-PRM21 DTM
Device setup Device setup allows the user to:
• Set the Unit number related to the actual PROFIBUS-DP Master
unit.
• Configure the communication link between the PC and the Unit.
This function invokes the User Interface of CX-Server.
• Test the Units communication link and to read out the Unit’s infor-
mation.
Master setup This function allows the user to define the Unit’s behavior in case of
• a network malfunction.
• a PLC mode change between PROGRAM mode and MONITOR/
RUN mode.
It also allows the definition of Auto-addressing, which simplifies I/O
data mapping.
Bus parameter setup The bus parameter setup allows the selection of baud rate and cal-
culation and editing of specific bus parameters.
Slave area setup The Slave area setup allows the user to define the I/O Data map-
ping of the I/O Data from each of the Slave stations on to the PLC
memory areas. This can be done automatically, but also allows edit-
ing by the user.
Monitoring functions • Master status read-out.
• Slave status and slave diagnostics read-out.
• Read-out of the Unit’s error log.
Support functions • Context sensitive help functions.
Generic Slave DTM
General functions The Generic Slave DTM reads the contents of a specific GSD file
located in a special sub-directory, and displays the setup options to
the user. It supports
• GSD file revisions 1 and 2 (PROFIBUS-DP functionality).
• GSD file revisions 3 (PROFIBUS-DPV1 functionality).
I/O Configuration setup The I/O Configuration setup function allows:
• Selection of Station address.
• Enable/disable watchdog.
• Overview of available I/O modules.
• Selection of I/O modules, including Addition, Insertion and
Removal of multiple modules.
Parameter setup The Parameter setup function:
• Setting of common as well as module dependent parameters.
• Setting of PROFIBUS-DP Extension parameters.
Group setting The Group setup function allows definition of the group to which the
associated Slave station will belong.
Monitoring functions The Monitoring functions provides a display of
• Standard Slave diagnostics flags.
• Extended diagnostics messages.
Support functions • Context sensitive help functions.
• Multi-language support.
Item Specification
