Omron E5CK User Manual

E5CK
5–39
Number of patterns
Ă• Sets the number of patterns that can be used in a program.
Setting Range
Default
1 to 4 1
ĂRelated parameters
Run all enable" (expansion mode)
Event input assignment 1" (option mode)
Program time unit
Ă• Specifies the time unit of the following parameters:
Pattern elapsing time monitor", Step 0 to 15 time"/Soak time 0 to 7", Time signal
1 ON time" Time signal 2 ON time" Time signal 1 OFF time" Time signal 2 OFF
time"
Setting Range
Default
“ ” :Hour, minute/ “ ” :Minute, second
ĂRelated parameters
Pattern elapsing time monitor" (level 1 mode)
Steps 0 to 15 time/Soak time 0 to 7" Time signal 1 ON time" Time signal 2 ON
time" Time signal 1 OFF time" Time signal 2 OFF time" (program mode)
Expansion Mode
Function
Setting
See
Function
Setting
See

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
