Omron E5CK User Manual

CHAPTER 5 PARAMETERS
E5CK
5–40
Step time/Rate of rise programming
Ă• Specifies the program method.
Setting Range
Default
“ ” :Set time/ “ ” :Rate of rise programming
ĂRelated description
3.5 Setting Patterns (page 3Ć14)
4.3 Ramp Rise Rate Setup Program (page 4Ć9)
ĂRelated parameter
Step 0 to 15 SP/Target SP 0 to 7" Ramp rate 0 to 7" Step 0 to 15 time/Soak time
0 to 7" (program mode)
Time unit of ramp rate
Conditions of Use
Rate of rise programming must be set.
Ă• Specifies the unit time of rate of rise 0 to 7."
Setting Range
Default
“ ” : Minute/ “ ” : Hour
ĂRelated parameter
Ramp rate 0 to 7" (program mode)
Expansion Mode
Function
Setting
See
Function
Setting
See

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
