6.4 Commands and Responses
E5CK
6–9
Parameter No. Parameter Data Setting Range Mode
57 Input type 0 to 21
59 Scaling upper limit Scaling lower limit +1 to 9999
58 Scaling lower limit -1999 to scaling upper limit -1
60 Decimal point 0 to 3
30 C/F selection 0: C, 1: F
61 Control output 1 assignment 0 to 4, 6, 10 to 13
62 Control output 2 assignment 0 to 4, 6, 10 to 13
63 Auxiliary output 1 assignment 2 to 4, 6 to 8, 10 to 13
et up
65 Alarm 1 type 1 to 11
66 Alarm 1 open in alarm 0: Closed in alarm, 1: Open in alarm
67 Alarm 2 type 1 to 11
68 Alarm 2 open in alarm 0: Closed in alarm, 1: Open in alarm
69 Alarm 3 type 1 to 11
70 Alarm 3 open in alarm 0: Closed in alarm, 1: Open in alarm
71 Direct/Reverse operation 0: Reverse operation, 1: Direct operation
28 Set point upper limit *1 Set point lower limit +1 to scaling upper limit
27 Set point lower limit *1 Scaling lower limit to Set point upper limit -1
72 PID / ON/OFF 0: Advanced PID, 1: ON/OFF
35 α 0.00 to 1.00
85 AT calculated gain 0.1 to 10.0
xpans
on
36 Automatic return of display mode 0 to 99
93 AT hysteresis 0.1 to 9.9
55 LBA detection width 0.0 to 999.9
*7 See page 5Ć29.
*8 0: Control output (heat), 1: Control output (cool), 2 to 4: Alarms 1 to 3, 6: LBA, 7 and 8: Errors 1 to 2, 10 to 11: Time signal 1 to 2, 12:
Program end, 13: Stage output
*9 See page 5Ć34.
*10 During temperature input, the range becomes the range of use of the selected sensor instead of the scaling upper/lower limit values.
