Omron E5GN User Manual

PARAMETER OPERATIONS LIST
E5GN
A–7
Initial setting level
Parameter Name Symbol Setting (monitor) Value Display Default Unit
Setting
Value
Input type *
Platinum
resistance
thermome-
ter
0 : Pt100
1 : Pt100
2 : Pt100
3 : JPt100
4 : JPt100
0 None
Thermocou-
ple
0 : K
1 : K
2 : J
3 : J
4 : T
5 : E
6 : L
7 : U
8 : N
9 : R
10 : S
11 : B
0 None
Non-contact
temperature
sensor
12 : K10 to 70_C
13 : K60 to 120_C
14 : K115 to 165_C
15 : K160 to 260_C
Analog input 16 : 0 to 50mA
Scaling upper limit
Scaling lower limit +1 to 9999
100 None
Scaling lower limit
-1999 to scaling upper limit -1
0 None
Decimal point
0.1
0 None
Temperature unit
_C, _F
,
_C None
Set point upper limit
SP lower limit +1 to input range
lower value (temperature)
1300 EU
SP lower limit +1 to scaling upper
limit (analog)
1300 EU
Set point lower limit
Input range lower limit to SP upper
limit -1 (temperature)
-200 EU
Scaling lower limit to SP upper limit
-1 (analog)
-200 EU
PID / ON/OFF
2-PID, ON/OFF
,
ON/OFF None
ST
ON, OFF
, ON None
Control period (OUT1)
1 to 99
20 Second
Control period (OUT2)
1 to 99
20 Second
Direct/reverse operation Direct operation, reverse operation
,
Reverse
operation
None
Alarm 1 type 0: Alarm function OFF
1: Upper- and lower-limit alarm
2: Upper-limit alarm
3: Lower-limit alarm
4: Upper- and lower-limit range
5: Upper- and lower-limit alarm
with standby sequence
6: Upper-limit alarm with standby
sequence
7: Lower-limit alarm with standby
sequence
8: Absolute-value upper-limit
alarm
9: Absolute-value lower-limit alarm
10: Absolute-value upper-limit
alarm with standby sequence
11: Absolute-valuelower-limit alarm
with standby sequence
2 None
Move to advanced func-
tion setting level
-1999 to 9999
0 None
