CHAPTER 5 PARAMETERS
E5GN
5–18
Input type
Ă• This parameter sets the sensor type by a corresponding code.
Ă• When this parameter is changed, the set point upper limit is changed to the default.
If the set point limits must be changed, set the set point upper limit" and set point
lower limit" parameters (initial setting level).
Ă• Set the code according to the following table. Shaded ranges indicate default settings.
The defaults are as follows.
Platinum resistance thermometer: 
": platinum resistance thermometer Pt100
Thermocouple: 
": K thermocouple
Input type Name
Set
Value
Input Temperature Range
Platinum resistance Platinum Pt100 0 -200 to 850 (_C) / -300 to 1500 (_F)
thermometer resistance
thermometer
1 -199.9 to 500.0 (_C) / -199.9 to 900.0 (_F)
thermometer
2 0.0 to 100.0 (_C) / 0.0 to 210.0 (_F)
JPt100 3 -199.9 to 500.0 (_C) / -199.9 to 900.0 (_F)
4 0.0 to 100.0 (_C) / 0.0 to 210.0 (_F)
Input type Name
Set
Value
Input Temperature Range
Thermocouple input Thermocouple K 0 -200 to 1300 (_C) / -300 to 2300 (_F)
type
1 -20.0 to 500.0 (_C) / 0.0 to 900.0 (_F)
J 2 -100 to 850 (_C) / -100 to 1500 (_F)
3 -20 to 400.0 (_C) / 0.0 to 750.0 (_F)
T 4 -200 to 400 (_C) / -300 to 700 (_F)
E 5 0 to 600 (_C) / 0 to 1100 (_F)
L 6 -100 to 850 (_C) / -100 to 1500 (_F)
U 7 -200 to 400 (_C) / -300 to 700 (_F)
N 8 -200 to 1300 (_C) / -300 to 2300 (_F)
R 9 0 to 1700 (_C) / 0 to 3000 (_F)
S 10 0 to 1700 (_C) / 0 to 3000 (_F)
B 11 100 to 1800 (_C) / 300 to 3200 (_F)
Non-contact K10 to 70_C 12 0 to 90 (_C) / 0 to 190 (_F)
temperature
sensor
K60 to 120_C 13 0 to 120 (_C) / 0 to 240 (_F)
sensor
ES1A
K115 to 165_C 14 0 to 165 (_C) / 0 to 320 (_F)
K160 to 260_C 15 0 to 260 (_C) / 0 to 500 (_F)
Analog input 0 to 50mV 16 One of following ranges depending on the
results of scaling:
-1999 to 9999, -199.9 to 999.9,
FĂRelated parameters
_C/_F selection" Set point upper limit" Set point lower limit" (initial setting
level)
Initial Setting Level
Function
Setting
See
