E5GN
5–19
Scaling upper limit
Scaling lower limit
Decimal point
The input type must be set to analog input.
Ă• These parameters can be used when voltage input is selected as the input type.
Ă• When voltage input is selected as the input type, scaling is carried out. Set the upper
limit in the scaling upper limit" parameter and the lower limit in the scaling lower
limit" parameter.
Ă• The decimal point" parameter specifies the decimal point position of parameters
(set point, etc.) whose unit is set to EU.
Ă• Scaling upper limit, Scaling lower limit
Parameter Setting Range Unit Default
Scaling upper limit Scaling lower limit +1 to 9999 None 100
Scaling lower limit -1999 to scaling upper limit -1 None 0
Ă• Decimal point: Default is 0: 0 digits past decimal point"
Set value Setting Example
0 0 digits past decimal point 1234
1 1 digit past decimal point 123.4
FĂRelated parameter
Input type" (initial setting level)
Initial Setting Level
Function
Setting
See
