CHAPTER 5 PARAMETERS
E5GN
5–20
_C/_F selection
The input type must be set to temperature
input.
Ă• Set the temperature input unit to either of _C" or _F".
Setting Range Default
: _C / : _F
FĂRelated parameter
Input type" (initial setting level)
Set point upper limit
Set point lower limit
Ă• This parameter limits the upper and lower limits when the SP is set. The SP can be
set within the range defined by the upper and lower limit set values in the set point
upper limit" and set point lower limit" parameters. The existing SP settings that are
out of the range are forcibly changed to one of the upper or lower limit values (whichĆ
ever is closest).
Ă• When the temperature input type and temperature unit have been changed, the set
point upper limit and set point lower limit are forcibly changed to the upper and
lower limits of the sensor.
Ă• During temperature input, the decimal point position is dependent on the currently
selected sensor. During analog input, it is dependent on the decimal point" parameĆ
ter setting.
Parameter Setting Range Unit Default
Set point upper limit Set point lower limit +1 to sensor range upper limit EU 1300
Platinum resistance thermometer EU 850
Set point lower limit Sensor range lower limit to set point upper limit -1 EU -200
FĂRelated parameters
Input type" _C/_F selection" (initial setting level)
Initial Setting Level
Function
Setting
See
Function
Setting
See
Initial Setting Level
