2 Basic Operations
2 - 22
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
z
Image control section
This is the same as in the Scene maintenance screen. Refer to Image control section on page 2-19.
z
Detail result
This is the same as in the monitor window. Refer to Detail result on page 2-17.
This editing screen allows you to set the system data.
System data is managed on a group basis and the editing items for each group are displayed by click-
ing the corresponding icon.
For details on each group, refer to 8-5 Changing the System Environment on page 8-8.
System data editing screen
No. Name
1Icon
2 Group name display area
3 Editing item display area
1)
3)
2)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
