Omron MC4700 - Figure 5-1 Connection Recommendations for LCM Metal Enclosure; Figure 5-2 Connection Recommendations for LCM DIN Box

LCM-3XX
SW2
SW1
0vdc
LCM-3XX
Out 1
Out 2
PLC
TB7
Switch Selection Connection
PLC Selection Connection
1
2
MPCE
Start
Prog
MCS
1
2
1
2
1
2
TB7
1
2
MPCE
Start
Prog
MCS
1
2
1
2
1
2
5
OMRON SCIENTIFIC TECHNOLOGIES INC.
Fremont CA USA
Tel: 1/888/510-4357 in USA and Canada
© OSTI 1209 PN99584-0050 Rev. E
Original Instructions
20
Figure 5-1 Connection Recommendations for LCM Metal Enclosure
RET
ECS 2
ECS 1
LCM-3
SW2
SW1
LCM-3
Out 1
Out 0
0vdc ref.
PLC
Switch Selection Connection PLC Selection Connection
+24 VDC
Earth
0 vdc
7
6
5
4
3
2
1
RET
ECS 2
ECS 1
+24 VDC
Earth
0 vdc
7
6
5
4
3
2
1
Figure 5-2 Connection Recommendations for LCM DIN Box
Switch Switch 2 Switch 1
Pattern1 0 0
Pattern 2 0 1
Pattern 3 1 0
Pattern 4 1 1
Note: 0 = Open, 1 = Closed.
Table 5-2 Switches for Multi Channel Select
