Response Time:
• MC4700 and MS4700
Table 14-1
Response Times for 12 mm systems
Protected Height Designator No. of Beams Response Times – mS
Solid State Mechanical Relay
N.O. N.C.
100 16 7.5 17.5 27.5
200 32 9.2 19.2 29.2
300 48 10.9 20.9 30.9
400 64 12.5 22.5 32.5
500 80 14.2 24.2 34.2
600 96 15.8 25.8 35.8
700 112 17.5 27.5 37.5
800 128 19.2 29.2 39.2
900 144 20.8 30.8 40.8
1000 160 22.5 32.5 42.5
1100 176 24.1 34.1 44.1
1200 192 25.8 35.8 45.8
1300 208 27.5 37.5 47.5
1400 224 29.1 39.1 49.1
1500 240 30.8 40.8 50.8
1600 256 32.4 42.4 52.4
Response Time for 12 mm MC4700 and MS4700
Note: MC4700-12 is only available up to 1200 mm protective heights.
