14.6.1 MSF4700 SERIES DIMENSIONS
Table 14-22 MSF4700-12 Dimensions
A mm/in. B mm/in. C mm/in.
102/4.0 185/7.3 214/8.4
202/8.0 285/11.2 314/12.4
302/11.9 385/15.2 414/16.3
402/15.8 485/19.1 514/20.2
502/19.8 585/23.0 614/24.2
602/23.7 685/27.0 714/28.1
702/27.6 785/30.9 814/32.0
802/31.6 885/34.8 914/36.0
902/35.5 985/38.8 1014/39.9
1002/39.5 1085/42.7 1114/43.9
1102/43.4 1185/46.7 1214/47.8
First & Middle Segment
Table 14-23
A mm/in. B mm/in. C mm/in.
102/4.0 169/6.7 198/7.8
202/8.0 269/10.6 298/11.7
302/11.9 369/14.5 398/15.7
402/15.8 469/18.5 498/19.6
502/19.8 569/22.4 598/23.5
602/23.7 669/26.3 698/27.5
702/27.6 769/30.3 798/31.4
802/31.6 869/34.2 898/35.4
902/35.5 969/38.1 998/39.3
1002/39.5 1069/42.1 1098/47.2
1102/43.4 1169/46.0 1198/47.2
MSF4700-12 Dimensions Last Segment
Table 14-24 MSF4700-14, MSF4700-20 and MSF4700-30 First and Middle Segment
A mm/in. B mm/in. C mm/in.
159/6.3 242/9.5 271/10.7
*235/9.3 318/12.5 347/13.7
309/12.2 392/15.4 421/16.6
*385/15.2 468/18.4 497/19.6
459/18.1 542/21.3 571/22.5
*535/21.1 618/24.3 647/25.5
609/24.0 692/27.2 721/28.4
*685/27.0 768/30.2 797/31.4
759/29.9 842/33.1 871/34.3
*835/32.9 918/36.1 947/37.3
909/35.8 992/39.1 1021/40.2
*985/38.9 1068/42.0 1097/43.2
1059/41.7 1142/45.0 1171/46.1
*1135/44.7 1218/48.0 1247/49.1
1209/47.6 1292/50.9 1321/52.0
*1285/50.6 1368/53.9 1397/55.0
