• A 4700 system with 12 mm minimum object resolution and two channels disabled has a minimum object
sensitivity of:
12 mm + 6.25 mm + 6.25 mm = 24.5 mm (0.96 inches).
If the size of the object detected by the 4700 system increases, the minimum safe distance must
increase. Use the minimum object sensitivity given in T
able 5-5, Table 5-6, Table 5-7 & Table 5-8 to
determine the new figure to use when computing the safety distance.
Table 5-5
Total Number of Beams
Disabled by Exact Channel
Select and/or Floating Blanking
Minimum
Object Resolution S
Depth Penetration Factor, Dpf
for use with
ANSI Formula (Dpf
= 3.4 (S-.276) inches)
None 12 mm (0.47 inches) 0.67 inches (16.96 mm)
1 Beam 19 mm (0.75 inches) 1.61 inches (40.93 mm)
2 Beams 26 mm (1.02 inches) 2.53 inches (64.25 mm)
3 Beams 33 mm (1.30 inches) 3.48 inches (88.43 mm)
4 Beams 40 mm (1.57 inches) 4.40 inches (111.75 mm)
5 Beams 47 mm (1.85 inches) 5.35 inches (135.93 mm)
etc...
Sample S and D
pf
Factors for 12 mm Resolution Systems
Table 5-6
Total Number of Beams
Disabled by Exact Channel
Select and/or Floating Blanking
Minimum
Object Resolution S
Depth Penetration Factor, Dpf
for use with
ANSI Formula (Dpf
= 3.4 (S-.276) inches)
None 14 mm (0.55 inches) 0.9 inches (24 mm)
1 Beam 25 mm (0.98 inches) 2.4 inches (61 mm)
2 Beams 36 mm (1.42 inches) 3.9 inches (99 mm)
3 Beams 47 mm (1.85 inches) 5.4 inches (136 mm)
4 Beams 58 mm (2.28 inches) 6.8 inches (173 mm)
5 Beams 69 mm (2.72 inches) 8.3 inches (211 mm)
etc...
Sample S and D
pf
Factors for 14 mm resolution Systems
Table 5-7
Total Number of Beams
Disabled by Exact Channel
Select and/or Floating Blanking
Minimum
Object Resolution S
Depth Penetration Factor, Dpf
fo
r use with
ANSI Formula (Dpf
= 3.4 (S-.276) inches)
None 20 mm (0.79 inches) 1.75 inches (44.45 mm)
1 Beam 31 mm (1.22 inches) 3.21 inches (81.53 mm)
2 Beams 42 mm (1.65 inches) 4.60 inches (118.96 mm)
3 Beams 53 mm (2.09 inches) 6.16 inches (156.86 mm)
4 Beams 64 mm (2.52 inches) 7.63 inches (193.76 mm)
5 Beams 75 mm (2.95 inches) 9.1 inches (231.16 mm)
etc...
Sample S and D
pf
Factors for 20mm resolution Systems
