Omron MC4700 - Figure 14-9 LCM Nema Metal Chassis Controller Dimension Drawing

. . . . .
OMRON SCIENTIFIC TECHNOLOGIES INC.
Fremont CA USA
Tel: 1/888/510-4357 in USA and Canada
© OSTI 1209 PN99584-0050 Rev. E
Original Instructions
85
14.7.2 LCM METAL CHASSIS CONTROLLER DIMENSION DRAWING
S cientific T echnologies Inc, Fremont C A 94555 -3611 US A
W A R N I N G
OP TI ONAL
QUI CK -DI S CONNECT
CONDUIT OR
BH-TYPE CONNECTOR
CONDUIT
OR
BH-TYPE CONNECTOR
LIQUID-TITE
FITTING
TOP VIEW
RIGHT SIDE VIEW
FRONT VIEW
LEFT SIDE VIEW
BACK VIEW
BOTTOM VIEW
10. 80
274. 3
10. 10
256. 5
2. 05
52. 1
0. 78
19. 8
5. 30
134. 6
KNOCKOUT
(2 PLCS)
Ø
0. 875
22. 2
KNOCKOUT
COMBO (4 PLCS)
Ø
0. 875/1.13
22. 2/28.7
KNOCKOUT
(2 PLCS)
Ø
0. 531/13.5
13. 49/342.9
THRU HOLES
(2 PLCS)
Ø
0. 843 or 0. 531
21. 4 or 13. 5
MTG HOLES
(8 PLCS)
Ø
0. 30
7. 6
4. 00
101. 6
3. 24
82. 2
1. 33
33. 8
1. 70
43. 2
1. 70
43. 2
1. 45
36. 8
2. 76
70. 1
6. 55
166. 4
9. 60
243. 8
11. 17
283. 7
7. 43
188. 6
1. 33
33. 7
1. 73
43. 9
1. 73
43. 9
1. 42
36. 1
11. 5
292
MIN.
1. 33
33. 8
0. 83
21. 2
1. 12
28. 3
1. 16
29. 5
Figure 14-9 LCM Nema Metal Chassis Controller Dimension Drawing
