Omron MC4700 - MSF4700 Spare Parts

. . . . .
OMRON SCIENTIFIC TECHNOLOGIES INC.
Fremont CA USA
Tel: 1/888/510-4357 in USA and Canada
© OSTI 1209 PN99584-0050 Rev. E
Original Instructions
79
Table 14-25
A mm/in. B mm/in. C mm/in.
159/6.3 226/8.9 255/10.0
*235/9.3 302/11.9 331/13.0
309/12.2 376/14.8 405/15.9
*385/15.2 452/17.8 481/18.9
459/18.1 526/20.7 555/21.9
*535/21.1 602/23.7 631/24.8
609/24.0 676/26.6 705/27.8
*685/27.0 752/29.6 781/30.7
759/39.9 826/32.5 855/33.7
*835/32.9 902/35.5 931/36.7
909/35.8 976/38.4 1005/39.6
*985/38.9 1052/41.4 1081/42.6
1059/41.7 1126/44.3 1155/45.5
*1135/44.7 1202/47.3 1231/48.5
1209/47.6 1276/50.2 1305/51.4
*1285/50.6 1352/53.2 1381/54.4
1359/53.5 1426/56.1 1455/57.3
*1435/56.5 1502/59.1 1531/60.3
1509/59.4 1576/62.0 1605/63.2
*1585/62.4 1652/65.0 1681/66.2
1659/65.3 1726/68.0 1755/69.1
*1735/68.3 1802/70.9 1831/72.1
1809/71.2 1876/73.9 1905/75.0
* Not available in 30 mm resolution
MSF4700-14, MSF4700-20 and MSF4700-30 Last Segment
14.6.2 MSF4700 SPARE PARTS
Table 14-26 Transmitter and Receiver Segments
1359/53.5 1442/56.8 1471/57.9
*1435/56.5 1518/59.8 1547/60.9
1509/59.4 1592/62.7 1621/63.8
*1585/62.4 1668/65.7 1697/66.8
1659/65.3 1742/68.6 1771/69.7
*1735/68.3 1818/71.6 1847/72.7
1809/71.2 1892/74.5 1921/75.6
* Not available in 30 mm resolution
MSF4700-12 Transmitters - First (X1), Mid (X2) and Last (X3) Segments
Model Number Description
MSF47-12-100-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 102 mm (4.0 in.)
MSF47-12-200-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 202 mm (8.0 in.)
MSF47-12-300-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 302 mm (11.9 in.)
MSF47-12-400-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 402 mm (15.8 in.)
MSF47-12-500-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 502 mm (19.8 in.)
MSF47-12-600-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 602 mm (23.7 in.)
MSF47-12-700-(X1, X2, or X3) MiniSafe Flexible MSF4700-12 Transmitter, 702 mm (27.6 in.)
