Table 14-19
MS4700-14 & -20
A in./mm B in./mm C in./mm
159.0/6.3 224.0/8.8 244.0/9.6
235.0/9.3 300.0/11.8 320.0/12.6
309.0/12.2 374.0/14.7 394.0/15.5
385.0/15.2 450.0/17.7 470.0/18.5
459.0/18.1 524.0/20.6 544.0/21.4
535.0/21.1 600.0/23.6 620.0/24.4
609.0/24.0 674.0/26.5 694.0/27.3
685.0/27.0 750.0/29.5 770.0/30.3
759.0/29.9 824.0/32.4 844.0/33.2
835.0/32.9 900.0/35.4 920.0/36.2
909.0/35.8 974.0/38.3 994.0/39.1
985.0/38.9 1050.0/41.3 1070.0/42.1
1059.0/41.7 1124.0/44.3 1144.0/45.0
1135.0/44.7 1200.0/47.2 1220.0/48.0
1209.0/47.6 1274.0/50.2 1294.0/50.9
1285.0/50.6 1350.0/53.1 1370.0/53.9
1359.0/53.5 1424.0/56.1 1444.0/56.9
1435.0/56.5 1500.0/59.1 1520.0/59.8
1509.0/59.4 1574.0/62.0 1594.0/62.8
1585.0/62.4 1650.0/65.0 1670.0/65.7
1659.0/65.3 1724.0/67.9 1744.0/68.7
1735.0/68.3 1800.0/70.9 1820.0/71.7
1809.0/71.2 1874.0/73.8 1894.0/74.6
MS4700-14 & MS4700-20 Dimensions
Table 14-20
MS4700-30
A mm/in. B mm/in. C mm/in.
159.0/6.3 224.0/8.8 244.0/9.6
309.0/12.2 374.0/14.7 394.0/15.5
459.0/18.1 524.0/20.6 544.0/21.4
609.0/24.0 674.0/26.5 694.0/27.3
759.0/29.9 824.0/32.4 844.0/33.2
909.0/35.8 974.3/38.3 994.0/39.1
1059.0/41.7 1124.0/44.3 1144.0/45.0
1209.0/47.6 1274.0/50.2 1294.0/50.9
1359.0/53.5 1424.0/56.1 1444.0/56.9
1509.0/59.4 1574.0/62.0 1594.0/62.8
1659.0/65.3 1724.0/67.9 1744.0/68.7
1809.0/71.2 1874.0/73.8 1894.0/74.6
MS4700-30 Dimensions
